WT-400 Chinese Cnc Vertical Machining Center Price Cnc Machining Center Accessories

Large aperture design High segmentation accuracy high rigidity and high performanceHigh efficiency and strong braking structure systemProduct ModelWT-400Segmentation accuracy15 ″Disk DiameterΦ400mmRepeat positioning4 ″Center DiameterΦ150H7mmLocking Mode200kg.mSpindle HoleΦ115mmServo Motorβ22is;HF-20......

Send Inquiry

Product Description

Large aperture design High segmentation accuracy high rigidity and high performance

High efficiency and strong braking structure system

Product Model	WT-400	Segmentation accuracy	15 ″
Disk Diameter	Φ400mm	Repeat positioning	4 ″
Center Diameter	Φ150H7mm	Locking Mode	200kg.m
Spindle Hole	Φ115mm	Servo Motor	β22is;HF-204
Center Height	255mm	Speed Reduction Ratio	1:120
T-Slot Width	14H7mm	Maximun Speed	33.3r.p.m
Positioning Button	18H7mm	Allowable Work Inertia	100kg.cm.sec2
Min lncrement	0.001°	Allowable Cutting Torque	170Kg.m
Weight(Without Motor)	320Kg	Vertical	200KG
Horizontal	500KG	Tailstock applied	500KG

Q: Are you trading company or manufacturer ? A: Our group consists in 3 factories and 2 abroad sales corporations. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: How long is your delivery time ? What is your terms of payment ? A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment. Q: What is the exact MOQ or price for your product ? A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation. If you have another question, please feel free to contact us.
