| TYPE | BMR-50 BMRW-50 BMRS-50 |
BMR-80 BMRW-80 BMRS-80 |
BMR-100 BMRW-100 BMRS-100 |
BMR-125 BMRW-125 BMRS-125 |
BMR-160 BMRW-160 BMRS-160 |
BMR-200 BMRW-200 BMRS-200 |
BMR-250 BMRW-250 BMRS-250 |
BMR-315 BMRW-315 BMRS-315 |
BMR-400 BMRW-400 BMRS-400 |
|
| Displacement(ml/r) | 51.7 | 80.5 | 100.5 | 126.3 | 160.8 | 200.9 | 252.6 | 321.5 | 401.9 | |
| Max.Pressure.Drop (Mpa) | cont. | 14 | 14 | 14 | 14 | 14 | 14 | 11 | 9 | 7 |
| int. | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 17.5 | 14 | 11 | 9 | |
| peak. | 20 | 20 | 20 | 20 | 20 | 20 | 16 | 13 | 11 | |
| Max.torque(N.m) | cont. | 93 | 152 | 194 | 237 | 310 | 369 | 380 | 380 | 380 |
| int. | 118 | 189 | 236 | 296 | 378 | 450 | 470 | 470 | 470 | |
| peak. | 135 | 216 | 270 | 338 | 433 | 509 | 540 | 540 | 540 | |
| Max. Speed (cont.)(r/min) |
770 | 745 | 595 | 475 | 370 | 295 | 235 | 185 | 150 | |
| Max.Flow(cont.)(L/mim) | 40 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | 60 | |
| Max.Output.Power(cont.)(Kw) | 7 | 10 | 10 | 10 | 10 | 8 | 6 | 5 | 4 | |
| Weight(Kg) | 6.5 | 6.9 | 7 | 7.3 | 7.5 | 8 | 8.5 | 9 | 11 | |
Intermittent operation the permissible values may occur for max.10% of every minute
Peak load:the permissible values may occur for max.1% of every minute
