Planetary Reducer Gearbox

Raydafon Group's Planetary Reducer Gearbox offers high precision and durability for industrial automation, featuring advanced planetary design that ensures smooth torque transmission, ideal for machinery and robotics users to enhance efficiency, reliability, and long-term performance, setting it apart with superior engineering and trusted quality.

Send Inquiry

Product Description

Key Specifications/Special Features:

Small Planetary Reducer Gearbox Motor with 8mm Diameter Metal powder metallurgy Gears

Specifications:

Rated voltage: 4.2V DC

Rotation direction: CW/CCW

Reduction ratio: 369/1

Operating temperature range: -10-50°C

Storage temperature range: -20-60°C

Overall length: 34.2mm

Gearbox length: 19.7mm

rated torque of gearbox: 750gf.cm

Instant torque of gearbox: 1,500gf.cm

Output power: 0.01W-0.5W

Output shaft: metal

Gears: metal

Housing: metal

No load:

Speed: 42rpm

Current: 100mA

On load:

Rated speed: 33rpm

Rated current: 160mA

Rated torque: 273gf.cm

Application:

Eyebrow pencil, camera, health care product, robot, and more

Electric shaver, tooth brush, kitchen appliances, hair clipper, sewing machines, massager, vibrator, hair dryer, rubdown machine, corn popper, scissor hair machine, vacuum cleaner, garden tool, sanitary ware, window curtain, coffee machine, whisk

Planetary Reducer Gearbox
