Model | Motor power | Working pressure | FAD | Noise | Connection | N.W. | Dimension | ||
L*W*H | |||||||||
KW | HP | Mpa | L/min | dB(A) | inch | kg | mm | ||
CMW2.2-0.8 | 2.2 | 3 | 0.2-0.8 | 255 | 49±3 | 1/2" | 132 | 670*630*945 | |
CMW3.7-0.8 | 3.7 | 5 | 0.2-0.8 | 415 | 52±3 | 1/2" | 150 | 720*680*1050 | |
CMW4.4-0.8 | 2.2*2 | 6 | 0.2-0.8 | 510 | 52±3 | 1/2" | 150 | 800*650*1020 | |
CMW7.4-0.8 | 3.7*2 | 10 | 0.2-0.8 | 830 | 55±3 | 1" | 185 | 880*720*1120 | |
CMW11-0.8 | 3.7*3 | 15 | 0.2-0.8 | 1245 | 58±3 | 1" | 300 | 1450*900*1150 | |
CMW15-0.8 | 3.7*4 | 20 | 0.2-0.8 | 1660 | 61±3 | 1" | 350 | 1450*900*1150 | |
CMW2.2-1.0 | 2.2 | 3 | 0.2-1.0 | 215 | 49±3 | 1/2" | 132 | 670*630*945 | |
CMW4.5-1.0 | 4.5 | 6 | 0.2-1.0 | 410 | 52±3 | 1/2" | 150 | 720*680*1050 | |
CMW4.4-1.0 | 2.2*2 | 6 | 0.2-1.0 | 430 | 52±3 | 1/2" | 150 | 800*650*1020 | |
CMW9-1.0 | 4.5*2 | 12 | 0.2-1.0 | 820 | 58±3 | 1" | 185 | 880*720*1120 | |
CMW13.5-1.0 | 4.5*3 | 18 | 0.2-1.0 | 1230 | 61±3 | 1" | 300 | 1450*900*1150 | |
CMW18-1.0 | 4.5*4 | 25 | 0.2-1.0 | 1640 | 61±3 | 1" | 350 | 1450*900*1150 | |
CMW3.0-1.2 | 3 | 5 | 0.2-1.2 | 210 | 49±3 | 1/2" | 135 | 670*630*945 | |
CMW4.2-1.2 | 4.5 | 6 | 0.2-1.2 | 360 | 52±3 | 1/2" | 150 | 720*680*1050 | |
CMW6.0-1.2 | 3*2 | 8 | 0.2-1.2 | 420 | 52±3 | 1/2" | 150 | 800*650*1020 | |
CMW9-1.2 | 4.5*2 | 12 | 0.2-1.2 | 720 | 58±3 | 1" | 185 | 880*720*1120 | |
CMW13.5-1.2 | 4.5*3 | 18 | 0.2-1.2 | 1080 | 61±3 | 1" | 300 | 1450*900*1150 | |
CMW18-1.2 | 4.5*4 | 25 | 0.2-1.2 | 1440 | 61±3 | 1" | 350 | 1450*900*1150 | |
