Custom High-Quality High Strength Stainless Steel Double Pitch Conveyor Chain with Extended Pin

Double Pitch Conveyor Chain with Extended PinThe extended pin conveyor chain is a deformed product derived from the standard roller chain. Its structural characteristics are the same as the traditional roller chain, except that the pin shaft is lengthened according to special requirements to fix the......

Send Inquiry

Product Description

Double Pitch Conveyor Chain with Extended Pin

The extended pin conveyor chain is a deformed product derived from the standard roller chain. Its structural characteristics are the same as the traditional roller chain, except that the pin shaft is lengthened according to special requirements to fix the raw materials or semi-finished products used in production. Such chains are primarily used in assembly lines, such as rubber production lines. The company can choose materials according to customer requirements, such as carbon steel, stainless steel, etc. The pin shaft can be customized with different diameters and lengths according to customer requirements.

The most common and widely used corrosion-resistant conveyor chain worldwide is made of stainless steel. This is due to the highly anti-corrosive properties of stainless steel, as well as the extensive range of temperatures and applications that stainless steel chains can operate in. 304-Grade Stainless Steel - This is the most common grade of stainless steel used because it is a non-magnetic material with good chemical resistance. It is highly resistant to corrosion and can operate in temperatures ranging from -200° to +700° Degrees Fahrenheit.

316-Grade Stainless Steel -This is the second most common grade used, which offers slightly better properties regarding chemical attack resistance and welding. We typically produce 316-grade stainless steel roller chains according to ANSI and DIN standards, but we can also supply other sizes and even specialty chains in 316-grade. Some benefits of using 316-grade stainless steel over 304-grade stainless steel are superior corrosion resistance, more excellent resistance to chemical attack, more durable, easier to clean, and more accessible to weld. In most applications, it will last longer. Something important to note about our stainless steel roller chains is that they are primarily austenitic and non-magnetic. 403-Grade Stainless Steel -This is primarily used for wastewater application chains, but we can manufacture standard and non-standard roller chains out of 403-grade stainless steel upon request. This grade of stainless steel has good impact strength, corrosion, and scaling resistance and is magnetic.

Product Name	Conveyor Chain With Extended Pin
Material	304 stainless steel, 316 stainless steel
Feature	Smooth, low noise, good quality, long life,resistance to wear
Colour	Nature
Surface Treatment	Self-color/sand-blasted/shot-peening
Model	Standard
Tensile Strength	Strong
Pitch	25.4~101.6mm
Quality	100% Inspection
Place of Origin	China
Warranty	3 years
Certification	ISO, ANSI, DIN,
Service	OEM ODM Customized
Application	Food Industry, Logistics Transportation Industry, Metallurgical Industry, Medicine Industry
Packing	Chain+Plastic Bag+ Carton+Wooden Case

Q: Are you trading company or manufacturer ? A: Our group consists in 3 factories and 2 abroad sales corporations. Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight. Q: How long is your delivery time ? What is your terms of payment ? A: Generally it is 40-45 days. The time may vary depending on the product and the level of customization. For standard products, the payment is: 30% T/T in advance ,balance before shippment. Q: What is the exact MOQ or price for your product ? A: As an OEM company, we can provide and adapt our products to a wide range of needs.Thus, MOQ and price may greatly vary with size, material and further specifications; For instance, costly products or standard products will usually have a lower MOQ. Please contact us with all relevant details to get the most accurate quotation. If you have another question, please feel free to contact us.

FOR MORE DETAIL, PLEASE CONTACT US.
