China Supplier Hydraulic Gear MotorGeroler Orbital Motorhydraulic Drive Wheel Motor

TYPEBMP-50BMPH-50BMP-80BMPH-80BMP-100BMPH-100BMP-125BMPH-125BMP-160BMPH-160BMP-200BMPH-200BMP-250BMPH-250BMP-315BMPH-315BMP-400BMPH-400Displcement(ml/r)52.979.398.2120.9158.7196.4241.8317.3392.9Max.Pressure. Drop(Mpa)cont.14141414141412108int.17.517.517.517.517.517.5141210peak.222222222222201513Max.......

Send Inquiry

Product Description

TYPE		BMP-50 BMPH-50	BMP-80 BMPH-80	BMP-100 BMPH-100	BMP-125 BMPH-125	BMP-160 BMPH-160	BMP-200 BMPH-200	BMP-250 BMPH-250	BMP-315 BMPH-315	BMP-400 BMPH-400
Displcement (ml/r)		52.9	79.3	98.2	120.9	158.7	196.4	241.8	317.3	392.9
Max.Pressure. Drop (Mpa)	cont.	14	14	14	14	14	14	12	10	8
	int.	17.5	17.5	17.5	17.5	17.5	17.5	14	12	10
	peak.	22	22	22	22	22	22	20	15	13
Max. torque (N.Mm)	cont.	97	148	183	229	295	364	369	404	416
	int.	125	189	238	292	382	470	444	501	531
	peak.	149	222	276	340	445	532	568	555	596
Max. Speed (cont.)(r/min)		755	750	610	490	375	305	245	185	150
Max. Flow (cont.)(L/min)		40	60	60	60	60	60	60	60	60
Max. Output. Power (cont.)(Kw)		6.5	10	10	10	10	10	8	7	5.7
Weight(kg)		5.6	5.7	5.9	6	6.2	6.4	6.6	6.9	7.4
