Description disc harrow:
Light duty disc harrow are suitable for pulverized loosening clods after ploughing and for planning the land before sowing on cultivated land.The machine can make soil and fertilizer mix up and clear aways the stump plants on light soil and prepairing seed bed for planting.
Specification of light duty disc harrow:
Model | 1BQX-1.1 | 1BQX-1.3 | 1BQX-1.5 | 1BQX-1.7 |
Overall size (CM) | 159*123*83 | 159*144*83 | 190*160*112 | 190*182*112 |
Weight (Kg) | 200 | 220 | 240 | 260 |
Working width (M) | 1.1 | 1.3 | 1.5 | 1.7 |
Working depth (Cm) | 8-14 | |||
Qty. of discs | 12 | 14 | 16 | 18 |
Dia. Of disc (Mm) | 460 | |||
Thickness of disc (Mm) | 3 | |||
Disc spacing (Mm) | 200 | |||
Productivity (Ha/h) | 0.7 | 0.84 | 0.97 | 1.1 |
Linkage | Three point mounted | |||
Matched Power (Hp) | 12-20 | 14-25 | 25-35 | 30-45 |
