The spindle head of boring and milling can match with several types of spindle and can be applied to several processing conditions, including boring, milling, drilling, tapping, twisting, grinding, etc. The spindle head of boring and milling can be installed on various machine production lines, common machine reformation and combination center machine. The accuracy of processed products is high, transmission is easier, design is more appealing and scientific.
Characteristics
•Dynamic sealing non-touching multi-maze waterproof structure is adopted in the design of spindle head to prevent external impurity of cutting fluid or dust, cutting scraps, etc. during production and processing, protect bearing from contamination and assure service lifespan and bearing accuracy.
•Central water outtake rotating joint can be equipped at the end of the spindle, which can be widely used in deep hole cutting and high-speed milling.
•The real roundness of the spindle head is<0.004mm, which is easy for high-speed operation, high dynamic-static accuracy and good stability.
•Standard alloy steel material is used for the spindle and goes through standard technology procedures, including hammering, several rounds of rough processing and finishing, re-finish machining, final finish grinding and cutting etc., to ensure durability and accuracy of the spindle.
•Housing is cast with accurate die and iron of high toughness and processed by means of manual vibration aging and natural aging to reduce stress and increase deformation resistance performance and stability.
•Compact structure, high mechanical efficiency, low noise, low vibration and high accuracy.
•Stable operation, no impact, prolongation of service life of spindle.
Our product can be adapted. Please give us the required model name so we can provide you the most accurate quotation.
This chart if for reference, if you need different features, provide us all relevant details for your project and we will be glad to help you finding the product matching your need at the best quality with the lowest price.
Please note the price and the MOQ may vary regarding the product you chose: do not hesitate to contact us to know more!
•NT50 is the traditional type with the taper of 7:24 and cutter installed with rear axle rod
• NT50 is enhanced spindle form of spindle head is automatic tool changer with the taper of 7:24
The booster-type unclamping cylinder is adopted for the spindle head, enabling compact structure and high-speed automatic tool change. It is mainly applied to full-automatic equipment and can store a certain quantity of cutter. Automatic tool changer completes the automatic exchange function of cutter by matching various tools available. Processing efficiency of the numerical control machine tool is further improved and one clamping is realized, namely and many processes can be completed. It is assembled into the CNC milling machine or component of the spindle system in the machining center.
Advantages of ATC:
•Non-cutting time is shortened, production efficiency is improved and non-cutting time is reduced to 20%-30%. The repeated operation of manual tool changing is avoided.
•Process is concentrated, so as to expand process range of the CNC numerical control machine tool and reduce floor space.
•Improve machining precision. Moreover, its characteristics enable high repeated positioning accuracy of the cutter, safety and reliability.
Advantages of CTS:
•External cooling: As the cooling liquid of the hollow internal cooling spindle is ejected from the cutter, the cooling effect of the cutting part acting on the workpiece and cutter is superior to the one of the common spindle, so that the surface quality of the machined part is better. The external cooling is affected by the rotary centrifugal force of the cutter, and most of cooling liquid is thrown away by the cutter, therefore, the cooling effect is bad.
•Internal cooling: It is more suitable for the deep hole working. When processing the deep hole, the cooling liquid is transported to the knife handle through the hole of the spindle center and ejected through the hole on the cutter, therefore, the cooling effect of the cutting part and workpiece of the cutter is obviously better than the one of the external cooling devices. Cuttings can be rapidly discharged through the spiral chute of the drill smoothly by virtue of the high-pressure cooling liquid, thus, realizing the continuous cutting, and improving the processing efficiency and cutter endurance.
•The cooling liquid can bring a part of heat through the spindle center hole when the spindle rotates and processes at high speed, which is better to improve service lifespan and precision of the spindle. It is able to avoid problems affecting the precision of the machine due to the thermal deformation of the spindle.
Low carbon steel, C45, 20CrMnTi, 42CrMo, 40Cr, stainless steel. Can be adapted regarding customer requirements.
Blacking, galvanization, chroming, electrophoresis, color painting, ...
High frequency quenching heat treatment, hardened teeth, carbonizing, nitride, ...
